- 304 stainless steel construction.
- The 4mm plate bending process is used to enhance the overall stability of the equipment.
- For fresh- and pool water.
- The equipment’s main power source and control (internal control board, drive, switching power supply) are integrated, which reduces the cost of cables, control cabinets, and control rooms for customers.
- The integrated DMX512 lighting device allows the light to better follow the water column. Compared with conventional CNC equipment, the Variable Nozzle/DMX512 can better reflect the perfect combination of water and light.
| Material | Stainless Steel 304 |
| Nozzle Diameter (mm) | DN65 |
| Weight (kg) | 35 |
| Length*Width*Height (mm) | 340*510*600 |
| Water Spray Height（M) | 15 |
| Reduction Ratio | 1:10 |
| Stepper Motor Operating Voltage | AC60V-90V |
| Total Power | 300W |
| Stepper Motor Phase Number | Two Phases |
| Stepper Motor Maximum Torque | 8.5(N.M) |
| Sensor Voltage | DC24V |
| Water Spray Range | 8m |
| Flow (m³/h) | 8.5 |
| Recommended Working Cables | JHS 2*6mm² |
| Recommended Control Cables | PVVP 3*1.5mm² |
| Water Inlet Diameter | DN50 |
| Lighting Configuration | HX130GM-DC24V-3*6W (RGB) |
