| Material | Stainless Steel 304 |
| Water Inlet Diameter | DN65 |
| Nozzle Diameter (mm) | DN50 |
| Length* Width* Height (mm) | L240*W420*L740 |
| Net Weight (kg) | 37 |
| Upper Dimension Reduction Ratio | 1: 10 |
| Lower Dimension Reduction Ratio | 1: 10 |
| Stepping Motor Working Voltage | AC55V-70V |
| Stepper Motor Power | 200W |
| Number Of Phases Of Stepper Torque | Two Phases |
| Upper Stepping Motor Maximum Torque | 8.5 (N.M) |
| Lower Stepping Motor Maximum Torque | 12 (N.M) |
| Sensor Voltage | DC24V |
| Upper (Lower) Dimensional Sensor Line Color Separation | Brown-24v Blue-Gnd Yellow-Return To Zero Signal |
| Upper (Lower) Dimensional Stepper Motor Line Color Separation | Red-A Green-A Yellow-B+ Black-B- |
| Recommended Stepper Motor Mounting Cables | JHS 4*2.5mm² |
| Recommended Sensor Mounting Cable | PVVP 3*1.0mm² |
| Mumber Of Slip Ring Lines | 7 |
| Net Weight (Kg) | 360° |
