| Material | Stainless Steel 304 |
| Nozzle Diameter (mm) | DN50 |
| Length* Width* Height (mm) | L313*W376*L735 |
| Net Weight (kg) | 37.65 |
| Upper Dimension Reduction Ratio | 1: 10 |
| Lower Dimension Reduction Ratio | 1: 10 |
| Stepping Motor Working Voltage | AC60V-80V |
| Stepper Motor Power | 200W, 260w |
| Number Of Phases Of Stepper Torque | Two Phases |
| Upper Stepping Motor Maximum Torque | 8.5 (N.M) |
| Lower Stepping Motor Maximum Torque | 12 (N.M) |
| Sensor Voltage | DC24V |
| Upper (Lower) Dimensional Sensor Line Color Separation | Brown-24v Blue-Gnd Yellow-Return To Zero Signal |
| Upper (Lower) Dimensional Stepper Motor Line Color Separation | Red-A Green-A Yellow-B+ Black-B- |
| Recommended Stepper Motor Mounting Cables | JHS 4*2.5mm² |
| Recommended Sensor Mounting Cable | PVVP 3*1.0mm² |
| Mumber Of Slip Ring Lines | 8 |
